Dongfeng T7 8*4 20TONS knuckle crane boom mounted on truck for sale, HOT SALE! 20tons cargo truck with crane
The truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Today, we will introduce hot sale dongfeng T7 8*4 LHD knuckle crane boom mounted on truck as below
high quality and competitive price dongfeng T7 8*4 LHD 240hp/270hp diesel truck with crane for sale
HOT SALE! best price Dongfeng 8*4 T7 knuckle crane boom with crane
Customized dongfeng T7 8*4 LHD knuckle crane boom with truck, adopts dongfeng T7 one row and a half driver cab, 2150+4400+1350mm wheelbase, yuchai 240hp/270hp Euro 5 diesel engine, fastgear 9 speed gearbox, 5.5tons front axle/10tons double rear axles, 11.00R20 rail tires, etc.
The cargo box body dimension(L*W*H) of the Dongfeng T7 20tons knuckle crane boom mounted on truck is 8500*2300*550(mm). client choose to install CLW Brand high quality 20tons knuckle crane boom.
The specification of Dongfeng T7 8*4 LHD 20tons knuckle crane boom mounted on truck as below.
| Product name | SINO TRUK HOMAN 4*2 LHD 4ton truck with crane(telescopic boom) |
| Truck chassis | ZZ1048D17EB1 |
| Parameters | Overall dimension length/width/height (mm) | 5995×2520,2350,2250×3200,2900,2700,3470 (mm) |
| Cargo body dimension (L*W*H)(mm) | 3450,3260×2400,2300,2150×600,550,400 (mm) |
| GVW(kg) | 4495 (Kg) |
| curb Mass(kg) | 3805 (Kg) |
| Rated mass(kg) | 495 (Kg) |
| Approach angle/ Departure angle(mm) | 20/16 (°) |
| Front suspension/rear suspension(mm) | 1175/1520 (mm) |
| Fuel Type | diesel |
| Max Speed | 90 |
| Engine | Type | YN38CRE1 |
| Displacement/Power(kw) | 3760ml/70KW/95hp; |
| Manufacturer | Yunnei engine; |
| Chassis | Drive Type | 4×2 |
| Wheelbase(mm) | 3300 |
| Tread(front/rear) | 1825/1615 |
| Transmission | Xiao 8 speed transmission, manual |
| Braking system | Air braking |
| Cab | 2080mm single row driver cab |
| Number of spring axle(front/rear) | 3/5+3 |
| Tire Type | 825R16 |
| Air-condition | Choose to fix |
| Upper part(cargo van and crane boom) main parameters |
| Upper body | Cargo body dimension | 3450,3260×2400,2300,2150×600,550,400 (mm) |
| Material | Carbon steel |
| Side sheet thickness | 2mm thickness |
| Bottom sheet thickness | 2mm thickness |
| Painting | Upon request |
| Crane boom main parameters |
| Crane boom | Choose to install CLW brand 4ton 4 sections telescopic crne boom |
| Max lifting mass | 4000kgs |
| Sections | 4 |
| Working radius | 11m |
| Lifting height | 13m |
| Rotation degree | ±360°full rotation, full hydraulic |
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us.
|
|
Dongfeng T7 8*4 20TONS knuckle crane boom mounted on truck for sale, HOT SALE! 20tons cargo truck with crane Images
|
